Extra Heavy Duty Fasteners

The Extra Heavy Duty T-End™ Fasteners have a high tensile strength which ensures secure shoe eyelet fastening in use with the Extra Heavy Duty T-End™ System. The fasteners can be used with large or small eyelets.

The Avery Dennison Mattress Fastening System eliminates messy sprays, hot melt glues, and water-based adhesives. Just insert the extra long heavy duty needle through multiple foam layers, and click. Mattress foam layers stay secure long after foams and glues fail and there's never any customer unfriendly crackling noise.The Mattress Fastening System eliminates curing time, secures flanges in a snap and can even fasten foam encasements. This system requires our Extra Heavy Duty T-End™ Fasteners, the EHD Industrial Long Needle Tool (10791-0), and it's replacement needle is 10792-0.

Attribute
Specifications
Class Extra Heavy Duty
Style T-End
Material Nylon
Nominal Applied Strength 14.5 lbs (6.60 kg)
Color Natural
Loading Type Clip
Per Clip 50
Package Quantity* 2.5M
Case Quantity* 50M

*M = 1000

Part # Nominal Filament Length
10760-0
SPC10760 (Europe)
1.1" (28mm)
10761-0 1.2" (31mm)
10762-0 1.3" (34mm)
10763-0 1.45" (37mm)
10764-0 1.6" (40mm)
10765-0 1.7" (44mm)
10766-0 1.8" (45mm)
10767-0 1.9" (49mm)
10768-0 2.0" (50mm)
10769-0 2.15" (55mm)
10770-0 2.3" (58mm)
10771-0 2.4" (61mm)
10772-0 2.5" (64mm)
10773-0 2.6" (65mm)
10774-0 2.7" (69mm)
10775-0 2.9" (73mm)
10795-0 3.2" (82mm)
