7.5" Double Headed Cable Ties

Our Double Headed Cable Ties feature an overall strap length of 7.5" (190.5mm). They allow you to harness two bundles simultaneously or provide a means to position and anchor a single harness.

Also available with an overall strap length of 11"(279.4mm).

Attribute
Specifications
Bundle Diameter 0.06"- 1.75" (1.6mm - 44.5 mm)
Width .177" (4.5mm)
Thickness .055" / 1.4mm
Minimum Tensile Loop Strength 50 lbf. (222 N)
Strap Length 7.5" / 190.5mm
Quantity Per Case* 5M

*M = 1000

Part # Environmental Requirements Color Operating Temperature Quantity Per Bag*
10424-0 General Purpose
 Natural -40 to 85°C / -40 to 185°F
 1M
10425-0 Heat Stabilized
 Black
 -40 to 105°C / -40 to 221°F
 1M
10426-0 Weather/UV Resistant
 Black
 -40 to 80°C / -40 to 176°F
 1M
10428-0 Heat Stabilized
 Black
 -40 to 105°C / -40 to 221°F
 100
Part # Panduit Cross Reference
10424-0 PLB2S-M
10425-0 PLB2S-M30
10426-0 PLB2S-M30
10428-0 PLB2S-C30
