20289-0

12.5mm Offset Oval LIFT™ Std Tie - PA66 IMHS Black

Offset oval fir tree ties allow you to guide harnesses, tubes, and hoses away from the mating hole when there is interference from other components or harnesses. The offsets are available in 12.5mm and 25mm distances and can be either a standard or a reverse pawl version. This single oval fir tree clip has the ability to fit or be mounted to a variety of hole sizes. This fastener is part of our Low Insertion Fir Tree (LIFT™) family of cable tie fasteners. LIFT ties offer an ergonomically advanced solution that provides a low insertion force while maintaining high retention characteristics.

Attribute
Specifications
ApplicationPunched Hole
Fastener TypeFir Tree
Mating FeatureOval / Rectangle Hole
Mount SizeOval Slotted Hole Sizes:
6.2 x 12.2mm
6.5 x 12.5mm
6.5 x 13.0mm
7.0 x 12.0mm
Bundle Diameter0.06 - 1.96" (1.6 - 50.0 mm)
Maximum Panel Thickness0.6 to 7.0 mm
Operating Temperature-40 to 125°C / -40 to 257°F
Material
Nylon 6/6, Impact Modified, Heat Stabilized
ResinPA66 IMHS
ColorBlack
Max. Insertion Force
10 lbf (44.5 N)
Min. Retention Force25 lbf (111.2 N)
Min. Loop Tensile Strength
50 lbf (222.4 N)
Strap Length209.5mm / 8.25"
Strap Width6.35mm / 0.250"
Strap Thickness1.35mm / 0.053"
Qty/Bag
1000/bag   5000/case
